Brand Name : BOE
Model Number : TDA190-001V02
Place of Origin : China
MOQ : 1 pcs
Price : Negotiable
Payment Terms : T/T, Western Union
Supply Ability : 100000 Unit/Units per Month
Delivery Time : 7 Days
Packaging Details : Original packaging/conventional packaging box
Model Name : TDA190-001V02
Diagonal Size : 19.0"
Panel Type : a-Si TFT-LCD, LCM
Resolution : 1280(RGB)×1024, SXGA 86PPI
Pixel Format : RGB Vertical Stripe
Active Area : 374.784(W)×299.827(H) mm
Touch Panel : Without
Application : Industrial \Outdoor High Brightness
TDA190-001V02 1280*1024 19.0 inch 800 cd/m2 LCD for Outdoor High Brightness
TDA190-001V02 LCD Panel Product details :
| BOE LCD SCREEN | |
| manufacturer | BOE |
| Model P/N | TDA190-001V02 |
| Diagonal Size | 19.0" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 1280(RGB)×1024, SXGA 86PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 374.784(W)×299.827(H) mm |
| Bezel Opening | 378.8(W)×303.0(H) mm |
| Outline Size | 396(W)×324(H) ×11.7(D) mm |
| Surface | Antiglare (Haze 25%), Hard coating (3H) |
| Brightness | 800 cd/m² (Typ.) |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 85/85/80/80 (Typ.)(CR≥10) |
| Display Mode | ADS, Normally Black, Transmissive |
| Best View on | Symmetry |
| Response Time | 8/8 (Typ.)(Tr/Td) |
| Display Colors | 16.7M 72% NTSC |
| Lamp Type | 5 strings WLED , 50K hours , Without Driver |
| Frequency | 60Hz |
| Touch Screen | Without |
| anel Weight | 1.72Kgs (Typ.) |
| Application | Industrial Outdoor High Brightness |
| Signal Interface | LVDS (2 ch, 8-bit) , 30 pins Connector |
| nput Voltage | 5.0V (Typ.) |
| Environment | Operating Temp.: -30 ~ 70 °C ; Storage Temp.: -30 ~ 70 °C |
| TDA190-001V02 1280*1024 19.0 inch 800 cd/m2 LCD for Outdoor High Brightness | |
TDA190-001V02 LCD Panel Shipping and Package :

TDA190-001V02 LCD Panel FAQ :
Q: Are you manufactory or trade company?
A: We are a Trade Company , We are LCD panel professional distributors ,We have own warehouse and inventory. Our goal is to provide our customers with the best products.
Q: Can you declared low value for my order when shipping?
A: Yes, We can do it for you if you need.
Q: How to do if I can't find the screen that I require in your listings?
A: We should have it in stock , please contact us directly.if we dont't have it , we can try our best to find it for you .
Q: Why big order delivery time are long?
A: All the lcd panel are Strictly tested before shipment , to ensure that you receive good quality lcd panel and work well!
|
|
TDA190-001V02 1280*1024 19.0 inch 800 cd/m2 LCD for Outdoor High Brightness Images |
